Easy steps in architecture and architectural drawing .. (1915)
Hodgson, Frederick Thomas, 1836- [from old catalog] · Chicago, Ill., Printed by F. J. Drake & co. · leaf 611
limit. Fig. 221. I offer a few simple examples herewith, … Fig. 222. and will follow them up with others of a morecomplicated nature. The illustrations shown at Figs. 221 and 222 ARCHITECTURAL DRAWING SELF TAUGHT 199 show the finished work, and working diagrams.The method of drawing these curves and orna-ments is quite apparent, the centers are allgiven,…
Architecture · Architectural drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
