Builders' architectural drawing self-taught : containing descriptions of drawing instruments and accessories, with rules for using them, and hints as to their care and management ... (1917)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919, Frederick J. Drake & Co · Chicago, F. J. Drake · leaf 225
and will follow them up with others of a morecomplicated nature. The illustrations shown at Figs. 221 and 222 ARCHITECTURAL DRAWING SELF TAUGHT 199 show the finished work, and working diagrams.The method of drawing these curves and orna-ments is quite apparent, the centers are allgiven, and the…
Architectural drawing · Architecture, Domestic
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
