at both ends ; load at any onepoint ; two triangles, apices at points of sup-port, bases at point loaded; BD2 propor-tional to distance from the nearest point ofsupport. Supported at both ends ; load distributed ;curves two parabolas, vertices at the middleof the beam ; bases center line of beam ;… … TRENTON BEAMS AND CHANNELS. 815 XUJEJffTOJtf BEAMS AJD CHA^aTEES.(Trenton Iron Works.) To find which beam, supported at both ends, will be required to supportwith safety a given ■uniformly distributed load : Multiply the load in pounds by the span in feet, and take the beam whose Coefficient for…
