e core aclick will be heard in the telephone owing to thecharge of the cable. 146 ELECTRICAL INSTRUMENTS. But if the connection be kept closed for a minuteor so the cable will be charged. Subsequent tapping will give no click if the in-sulation be good. The clicks are of course due tocurrent… … Fig. 84. nection, L a lead from the cable core to the gal-vanometer connection. K is a short circuit key,that is, one which can be left closed to short cir-cuit and cut out the galvanometer and also beopened to cut in the galvanometer. Before connecting L to the cable, test the insu-lation of L.…
