Fig. 15. Between A and B is the main machine voltage suppliedto transformers for the lighting circuits. When inductionmotors are to be supplied, a third wire from ring C andtwo transformers are required. Fig. 15 represents themethod of connecting up the transformers for power pur-poses on…
