w the projections of a hexagonal nut, Fig. 366,for a bolt whose diameter d is equal to 1. Scale, full size. F=i\d+\. D=FXi.iSS- H=d- Construct the plan first. Draw the chamfer circle F andcircumscribe a hexagon about it with the 30°X6o° triangle andT-square. Project elevation and end elevation from… … 284 MECHANICAL DRAWING. elevations from it. A square nut should never be shown inelevation across the corners. Prob. 8. Make drawings for 1 bolt with castle nut, Fig. 368.Scale, full size. The values of the letters in the figure are to be taken fromTable 3 which gives the standard proportions…
