International Library of Technology · Scranton, International Textbook Co. · leaf 206
that an instrument thus arranged would nie9,sure resistances 1640 ELECTRICAL- MEASUREMENTS. TT^TT of varying from 1,111 times the largest value of P tothe smallest value of P. For bridge measurements requiring a considerable degreeof accuracy, it is best to use a sensitive reflecting galva-nometer,… … Galv. FIG. 1004. arm N, A B C D to arm P, and x to the unknown resistance.K, K are the keys for closing the battery and galvanometercircuits, respectively. The number against each coil rep-resents the resistance of that coil. It will be seen that withthe resistances m. A B C D, ,a great number of…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 206](https://img.insideoutlibrary.com/img/1024/ia-electricengineer01inte-206-87.webp)
