ments could be made in the formof a single four-segment commutator, as represented in Fig.1159. 3099. In this new arrangement each segment of thecommutator is made up of two of the segments shown in tne 1958 APPLIED ELECTRICITY. original scheme. These parts have been lettered to corre-spond with… … FIG. 1159. them at exactly the same part of the revolution as theterminal brushes (the brushes connected directly to the ex-ternal circuit, 1 and Jf. and 2 and S, Fig. 1158) in the origi-nal scheme shown in Fig. 1158, and the connections madeby the intermediate brushes {2 and 3 and 1 and 4,…
