winding and arrangement of the connections. Theconditions which govern the design of a winding for a com-mercial machine and the actual construction of the windingwill be taken up later. RING WINDINGS. 3123. The simplest form of ring winding is that alreadydescribed, in which the conductor forms a… … Fig. 1165. If a simple ring-wound armature is placed in a multipolarfield, each adjacent pair of poles will act on the winding in APPLIED ELECTRICITY. 1975 the same manner as a bipolar field, so that that section of thearmature will be divided into two parallel circuits. Thewhole winding will,…
