International Library of Technology · Scranton, International Textbook Co. · leaf 168
the mains through aswitch and fuse block as before. The motor connections MOTOR DESIGN. 2543 are somewhat simpler than in the last case, one terminal ofthe armature A being connected at a to one terminal of thefield, c and d forming the two terminals of the motor.The starting rheostat C is simply… … Fig. 1423. the required starting torque. On account of the fieldwinding acting to a certain extent like a starting resistance,series motors do not require as large an amount of resist-ance in the starting rheostat as shunt motors. This fea-ture is of value in street-railway work, as it permits the…
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 168](https://img.insideoutlibrary.com/img/1024/ia-electricengineer02inte-168-76.webp)
