Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship (1893)

Langmaid, Joseph, Gaisford, H · London, New York : Macmillan · leaf 85

An illustration from Elementary lessons in steam machinery and the marine steam engine, with a short description of the construction of a battleship, 1893, leaf 85
63 … Fig. 33.—Cross Section of Shaft in Lignum Vit.e Bearing.(Page 69.)

Steam-engines · Marine engines

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
