ibution is, however,always accompanied by a lowering of the E. M. F. generated, 2754 DESIGN OF ALTERNATING even though the total number of turns be kept the same.Suppose, for example, we have a single-phase armature withT turns, or 2 T conductors, connected in series and arrangedwith only one slot… … Fig. 1589.distribute these slots equally around the armature. Wewill put half as many conductors as before in each slot, so thatthe total number of conductors and turns will remain thesame as before. This will give us a winding similar to thatshown in Fig. 1589. This shows an 8-pole…
