International Library of Technology · Scranton, International Textbook Co. · leaf 22
rectly above, but a better one is tomake use of countershafts on the engine or dynamo floor, orboth. These countershafts are divided into sections andfitted with friction pulleys in such a way as to permit of anydesired combination of engines and dynamos, an arrange-ment best calculated to ensure… … Fig. 3. 14 ELECTRIC TRANSMISSION. above the flywheels and connected by belting to the dyna-mos d. Two engines are indicated, their flywheels w, wbeing dotted in the plan.
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 22](https://img.insideoutlibrary.com/img/1024/ia-electricengineer03inte-22-2.webp)
