connect them to switch-board leads o, p. By con-necting to the cross-wire,as shown at k, /, line 1 isconnected to o, and by con-necting as shown at m, nline 1 is connected to p.By this arrangement, there-fore, the line and switch-board connections may betransferred in any way de-sired. The actual… … Wooafenframe. org/a^s I TftrearfeaPrass ro<?(b) •so/dererffo wire. FIG. 36. § 19 ELECTRIC LIGHTING. 59 connector, somewhat similar to that shown in Fig. 36 (a).Different methods are used for stretching the wires on theframe, but they should always be mounted so that theywill be thoroughly…
