rrent through 31 ELECTRIC RAILWAYS. what is practically a portion of one turn only, whereas inthe small meters several turns are required. The reading(watt-hours) is obtained in the same way as for the ordinarystyle of meter, and by keeping a record of the readings, theoutput of the station for any… … FIG. 1. surrounding the heavy conductors on the back of the boardaffected the meter. In this meter any stray field afi:ects boththe armatures c^ r, which are so connected that an outsidefield tends to turn them in opposite directions, and the dis-turbing effect is thus neutralized. The field set up…
