shows the memberthat fits into the woodencase shown in Fig. 22; a, a are two lugs provided withholes e, e to take the ends of the trunk wire and screws b, bto secure the wire in place; r, c are also two lugs providedwith thumbscrews to take such a special fuse wire as isshown in Fig. 23 {b). This… … Fig. 22. c 1 (a) (n)===<ai Fig. 23. cases the car is provided with a fuse of the proper size. Onone side, a and <:, Fig. 23 {a)^ are connected directly together,but on the other side they are connected through coil d,which has an iron core so disposed as to throw a strongmagnetic field across…
