International Library of Technology · Scranton, International Textbook Co. · leaf 482
the figure shows the rigging on only one side of thetruck. 65. Fig. 63 shows two such truck riggings adapted toa double truck; the long lever/^Pis secured to the car bodythrough fulcrum F^ which is, therefore, stationary. Fig. 64shows the device used to compensate for the rotation ofthe truck on… … 50 ELECTRIC RAILWAYS. 25 respective trucks connect to their ends. Tension rods X, Ycarry on their ends a grooved wheel through which the A
Electrical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
![An illustration from [Electric engineering.], 1902, leaf 482](https://img.insideoutlibrary.com/img/1024/ia-electricengineer04inte-482-252.webp)
