Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice (1918)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 63

An illustration from Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice, 1918, leaf 63 — middlewheel from one arm of a lever above the other carr>dng a balanc-ing weight. Some forms of pulley block dynamometer omit the middlewheel and weigh the reaction of the bearing on the transmissionshaft directl3\ When this is done, the transmission shaft must bearranged to rest freely on the… … Fig. 26.—Webber Dynamometer. supported by a lever whose fulcrum lies on the common axisof the driver and transmission shafts, Similar to the principleshowTi by Fig. 25 the net force on the middle gear is 2F, Thisis balanced by the dead weight T7 acting with a lever arm of Rfeet. Taking moments of…

Mechanical engineering laboratories
