Audels answers on automobiles, for owners, operators, repairmen ... including chapters on the storage battery, electric vehicles, motor cycles, overhauling the car, etc. Fully illustrated and indexed (1911)
Booth, Charles Edwin, b. 1849 · London, New York, T. Audel & co · leaf 175
e, and the so-calledhigh tension types in which the secondary coil is containedwithin the magneto, or in a separate box, usually placed onthe dash. 148 A UDELS ANSWERS Ques. How is the ignition current delivered to the variouscylinders in proper order? Ans. This is accomplished by a self-contained… … PRIMARY CIRCUIT SECONDARY CIRCUIT GROUND CIRCUIT THROUGH FRAHE l*ig. 64.—Circuit diagram of a magneto with self contained coil. A isthe armature winding; P, primarj of transformer; S, secondary of transformer;D, distributing brush carrier; E, contact segments; F, safety spark gap; G, ter-minals to…
Automobiles
