a-tory instrument arranged with a transparent scale. The galvanometer isonly 5 inches in diameter, and has a transparent scale graduated in 50parts, central zero, with zero shifting device. This instrument is made froma specially designed Weston movement, possessing all of the character- 340… … FlG. 421. — Weston Projecting Instruments. throw double-pole switch is usually arranged so that the galvanometerterminals come to the middle of the switch ; the switch when thrownin one direction indicates volts, and when thrown in the other directionindicates amperes. For speed measurements a…
