effect on the shape ofthe wave, but follow the shape of the E. M. F. wave like anyother secondary current. In their influence upon the pri- * On the Law of Hysteresis, Part III, A. I. E. E. Transactions, 1894,P- 595- 114 HYSTERESIS—MOLECULAR MAGNETIC FRICri^N. mary current they also act like a… … Figs. 43 and 44. Bradlcj i Poalee, Engrt, N. T. -Distortion of Current Wave by Hysteresis. In Fig. 43 is shown the current wave in a transformer atpartial secondary load, showing the reduction of the distortionunder load. The dotted line y]/represents the magnetic flux. HYSTERETIC LOSSES. II5 In a…
