The electric motor and the transmission of power (1906)
Houston, Edwin J. (Edwin James), 1847-1914, Kennelly, Arthur E. (Arthur Edwin), 1861-1939, joint author · New York : McGraw Pub. Co. · leaf 46
ufficient to operate mostreceptive devices, it is necessary to in-crease it by connecting a number of sepa-rate cells together so as to permit them toact as a single cell or battery. Such con-nection may be effected in various ways,but the readiest is connection in series^which consists essentially… … Fig. 2.—Voltaic Battery of Three Cklls in Series. shown in Fig. 2, whcTC thTce separate,Daniell gravity cells are connected inseries. If the E. M. F. of each cell is, say1.1 volts, the E. M. F. of the battery willbe 3.3 volts. Dynamos may also be con-nected in series, but since it is easy…
Electric motors
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
