Electric toy making for amateurs. This work treats on the making of electrical toys, electrical apparatus, motors, dynamos and instruments in general ... By T. O'Conor Sloane .. (1914)

Sloane, T. O'Conor (Thomas O'Conor), 1851-1940 · New York, The N.W. Henley publishing co. · leaf 129

An illustration from Electric toy making for amateurs. This work treats on the making of electrical toys, electrical apparatus, motors, dynamos and instruments in general ... By T. O'Conor Sloane .., 1914, leaf 129
Fig. 54. An Easily Constructed Motor. AN EASILY CONSTRUCTED MOTOR. 129 The pole pieces are bored or filed out to just cleara 1^-inch armature. The armature is of the three-pole type and shouldhe made of laminations of thin soft sheet iron cut tothe shape and size shown in Fig. 55. A simple andeasy…

Electric apparatus and appliances · Electric toys
