An elementary book on electricity and magnetism and their applications (1919)
Jackson, Dugald C. (Dugald Caleb), 1865-1951, Jackson, John Price, b. 1868, Black, Newton Henry, b. 1874 · New York, The Macmillian Co · leaf 253
ls ; B, flux due to arma-ture windings ; C, resultant flux distribution. be noted that the armature magnetic field is at right anglesto that produced by the field magnets. It will also be observedin diagram C that the resultant distribution of magnetic fluxhas shifted the neutral line in the…
Electricity · Magnetism
