Hawkins electrical guide ... : questions, answers & illustrations : a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications ; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833-1928 · New York : T. Audel & Co. · leaf 19
al diagram the inductors of the armature arerepresented by short radial lines, while the end connectorsare represented by curves or zigzags, those at one end of thearmature being drawn within, those at the other end, withoutthe circumference of the armature. With the radial diagramit is easier to… … Fig. 255.—Partial sketch of a four pole machine laid on its side. If the observer imaginehimself placed a£ the center, and the panorama of the four poles to be then laid out flat,the developed view thus obtained would appear as in fig. 256. is considered as though the entire structure had been…
Electrical engineering
Internet Archive · Brigham Young University · Public Domain Mark 1.0. Free to use for anything.
