An elementary book on electricity and magnetism and their applications (1919)
Jackson, Dugald C. (Dugald Caleb), 1865-1951, Jackson, John Price, b. 1868, Black, Newton Henry, b. 1874 · New York, The Macmillian Co · leaf 75
allel and part of conductors in series, it is necessary tocalculate the joint resistance of the first part and then addthat to the resistance of the remainder of the circuit which isin series with the branched portion. It is easily seen thatthe joint resistance of conductors in parallel is equal to… … Fig. 26. 7>^OHMS— Compound circuit. ELECTRIC CIRCUITS AND FLOW OF ELECTRICITY 57 in ohms of the different parts are as marked; then the resist-ance of the complete circuit is 6 + 34 1 1125^T5 or 12 ohms. If the voltage developed by each of the two cells, which arerepresented by the usual sign…
Electricity · Magnetism
