Elementary cabinetwork for manual training classes (1909)
Selden, Frank Henry. [from old catalog] · Chicago, New York [etc.] Rand, McNally & company · leaf 197
Fig. 186. Library table making Figs. 179 and 182, as they apply quite closelyto the work on Fig. 186. The turning on this tableis not so difficult as that on Fig. 183, and may bedispensed with entirely. The shelf rests on the top of the lower rails,avoiding the joints at the ends of the shelf. The … TABLES 191 shelf and cross rails beneath the shelf may beomitted. If these parts are not used, the joints atthe upper end of the legs must bear all the strain.Unless there is a shelf, the legs should be tapered(Fig. 179). Legs turned the entire length below therails may be used on such tables. As…
Cabinetwork
