lace the clamp in thevise (Fig. 15), and lay off the mortises. The loca-tion of the mortises in the back may be determinedby first making marks at the corners and then carry-ing these marks across the edge after the clamp has 32 ELEMENTARY CABINETWORK been removed. These marks, much exaggerated,… … Fig. 15. Lining chair legs are not alike, small marks locating them should bemade at the corners before the clamp is removed. The proper corner in which to place the marksis indicated by the position of the visible face mark. MORTISES AND TENONS ^^ The legs may be clamped together; the two backones…
