Elementary course in woodwork ; designed for use in high and technical schools, with one hundred and thirty-four illustrations, by George Alexander Ross (1901)
Ross, George Alexander · Chicago, New York, A. Flanagan Company · leaf 40
FlG 41 36 ELEMENTARY COURSE IN WOODWORK fectly straight across; straight lengthwise, and freefrom twist). Side here used means one of the wider surfaces indistinction from the narrower surface, the edge. Methods for testing the surface with parallel strips,etc., will be shown by the instructor.… … S.42, THIRD. Set the gauge, Fig. 42, to the width given in thedrawing, and gauge a line from the face edge on bothsides; then plane to the gauge lines. In using the gauge seethat it is held as shown inFig. 43, and push awayfrom the body, having thepressure on the gauge asshown by the line A, B,Fig.…
Woodwork (Manual training)
