\ — 22. The latter gradually dies down, with the duration T = —, on the usual exponential tran- 30 I SINGLE-ENERGY TRANSIENTS. 31 sient, shown dotted in Fig. 15. Adding the transient current ioto the permanent current 22 gives the total current during thetransition period, which is shown in drawn… … Fig. 15. — Single-energy Transient of Alternating-current Circuit. thus is the larger, the greater the difference between the twocurrents, the previous and the after current. It thus disappearsif the change occurs at the moment when the two currents iiand 2*2 are equal, as shown in Fig. 155, and is…
