Fig. 2. kind, called a sine curve, may be constructed in the followingmanner. ^ Take any line OX on which to mark off time (see Fig. 3), andwith 0 as centre describe a circle with diameter AB. Divide its … DX Fig. 3. circumference into 12 parts, and through these points drawhorizontal ines. Take any length BD on the horizontal line anddivide It a so into 12 parts and through these points draw linesperpendicular to OX to intersect the horizontal lines drawnthrough the 12 points on the circumference of…
