Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 190
SUPPORTERS AND CRANK MOTIONS. 11& the measurements of its parts. This will suffice for the frame,but the motions of the train must be understood, so as to knowwhat position to give to other parts, corresponding to a givenposition of some one part. 4. In some machines, however, there are…
Geometrical drawing · Mechanical drawing
