Stereotomy : Problems in stone cutting. In four classes. I. Plane-sided structures. II. Structures containing developable surfaces. III. Structrues containing warped surfaces. IV. Structures containing double-curved surfaces. For students of engineering and architecture (1875)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York : J. Wiley and son · leaf 124
ger dimensions, and less declivity of face, which would begenerally found in practice, the part from X to F would benearly a vertical plane, and from BE to X, nearly a conical,or even an almost vertical cylindrical surface. Hence, in sucha case the coursing surfaces could be safely horizontal… … STONE-CUTTING. 97 II. The Directing Instruments and their Application. Asevery surface, except the back, which would generally be leftrough, of all the stones between UU and gg is warped, nopatterns can be used. It would therefore be best to begin, atleast, by working some one surface by the method…
