Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)
Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 250
rical;tint them with pale burnt sien-na, and the shoe, S, with prus-sian blue, the conventional tintfor iron. i. Rule the water in blue lines,distributed as in the figure. j. Tint the dirt in fine horizon-tal strokes of any dingy mixture, Note.—The above figure shows a little more than half of a… … 150 WOODED STRUCTURES. in which burnt sienna prevails, in the parts above the water,and ink, in the muddy parts below the water, and then add, ornot, the pen strokes shown in the plate, to represent sand,gravel, &c. k. Place heavy lines on the right-hand and lower edges of allsurfaces, except…
