to the free ends of the armatures. Themagnetic condition of the armatures and cores is indicatedin the figure ; the latter have a permanent polarity equalto the magnetic effect of 18 m.a. of current, and if thearmatures are exactly central, equal attraction is exerted,but a very slight displacement… … B wiiidiii the current ceases the tongue returns to the spacingcontact. A positive current entering at (U) will strengthenthe polarity of the right-hand core and Aveaken the left-hand or, if strong enough, reverse it. The attraction andrepulsion of the four jDolepieces tend to make the relayvery…
