A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 376

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 376
keep the two endless belts (onefor each wheel and series of four pulleys) taut. When the machine is in operation, each endlessleather belt covers a frictional surface of about thewhole of the lower half of its circumference, of itscorresponding rubber belt, which drives its leather 375 belt,… … Fig. 22. The cloth is fed into the machine through tensionrails 7 and 8, and round governor tension 9, embed-ding each selvage between one of the endless leatherbelts (one on each side! and the rubber belt cover-ing on face of its corresponding large revolving wheel1 or 2, which conveys it (the…

Textile fabrics · Textile industry · Textile machinery
