Niaudet, Alfred, 1835-1883. [from old catalog], Fishback, L. M., [from old catalog] tr · New York, J. Wiley & sons · leaf 149
es 130 TWO-LIQUID BATTERIES. closed by the sulphate of zinc at the top; a constant de-rived current is thus produced, and consequently the dif-ference of potential is diminished between the electrodes, SIK WILLIAM THOMSONS BATTEEY. This illustrious physicist invented a very original dis-position of… … Fig. 33. on the inside with lead to make them, water-tight. Atthe bottom of each tray is placed a thin plate of copper.In the four corners of this square tray are little blocks ofwood which support the zinc electrode. This latter hasthe singular form of a gridiron, having its bars very close,but…
Electric batteries
