Niaudet, Alfred, 1835-1883. [from old catalog], Fishback, L. M., [from old catalog] tr · New York, J. Wiley & sons · leaf 47
rst; by uniting the positive pole to the 28 SINGLE-LIQUID BATTERIES. positive pole, and the negative to the negative, in sucha manner as to have two poles of the same name endingat the galvanometer (Fig. 9), the needle will remainstationary. This is not to be wondered at, if it be re-membered that… … Fig. 9. said in this case that the two battery cells are opposed toeach other, or are joined in opposition. We have assumed, in the preceding, that the opposedcells were of equal dimensions. Each one acting alonewould produce the same deflection of the needle, one to-wards the right and the other…
Electric batteries
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
