her two. If all threesides of the triangle drawn are not of equal length, the 30° and 60° angles are not accurate.Fig. 6 shows themethod of using thetriangle in connectionwith the T-square, theleft hand manipulatingand holding the triangleand the T-square.The draftsman shouldarrange his work so as… … Fig. 6. — Using the Triangle in Connection withthe T-square.
Mechanical drawing
