The elements of dynamic electricity and magnetism (1903)
Atkinson, Philip. [from old catalog] · New York, D. Van Nostrand company · leaf 37
electrodes are attached to a close-fitting, insulating cover. The Diamond Carbon Cell.—The Diamond Carbon Cell,shown in Fig. 7, is another of the same class, in whichthe conducting electrode consists of seven round rodsarranged in a circle around the zinc rod, and put inelectric connection with… … FiG. 6. ONE-FLVID CMLLB. 21 polarization as the last. The metal cover reduces itsresistance, and the separate rods are easily renovatedby heating or soaking in hot water when necessary, andcheaply replaced when worn out. In other cells of this class, as the Laclede and Mi-
Electricity · Magnetism
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
