Elements of mechanism: elucidating the scientific principles of the practical construction of machines, for the use of schools, and students in mechanical engineering, with numerous specimens of modern machines, remarkable for their utility and ingenuity (1852)

Baker, T. (Thomas), d. 1871 · London, J. Weale · leaf 87

An illustration from Elements of mechanism: elucidating the scientific principles of the practical construction of machines, for the use of schools, and students in mechanical engineering, with numerous specimens of modern machines, remarkable for their utility and ingenuity, 1852, leaf 87
lacing the pins close to the large end of d, and the. second by fixing them at the small end ; and when the pins are fixed in any intermediate position, an intermediate velocity ratio will be obtained.” — See Prof. Willis's Mechanism, Art. 280. THE EXCENTRIC CROWN-WHEEL. 103. “ If the axis be not… … meets that of a b in direction, and is at right angles to it. How, since the radius of contact of the pinion is constant,

Mechanics · Machinery, Kinematics of · Machine-tools

Internet Archive · Smithsonian Libraries · Public domain (published before 1931). Free to use for anything.
