Sullivan, Christine [Gordon]. [from old catalog] · New York, Cincinnati [etc.] American book company · leaf 24
, describe anarc, and locate the point S. Through thepoints O and 6 draw lines from B^ dividingthe angle as required. Problem 10.— To construct a rectanglewhose sides shall be equal to two given lines. Let AB and CD (Fig. 30) be the givenlines. Draw the straight line EF equalto CZ>, and from E… … 20 ELEMENTS OF MECHANICAL DRA WING.
Mechanical drawing
