Elements of mechanical drawing (1893)
Sullivan, Christine [Gordon]. [from old catalog] · New York, Cincinnati [etc.] American book company · leaf 50
Fig. 74. Fig. 75. Exercise 10. — Draw a hemisphere withdiameter of 4 feet (Fig. 76) ; also planand elevation (Fig. 77).Mechanical drawing
