dis to space the following title in the usual letter space: * In lettering this and all other sheets, and for all lettering, use the styles ofletters given in Chapter II and not the type letters appearing on the plates. SKETCHING. 155 SHEET NO. 4.Letter-sheet No. 2. Name. Date. 176. Sheet No.… … THE CETAIL Fig. 70. 177. Sheets Nos. 6 to 20, Inclusive.—These sheets are to bescale drawings from models, such as could be taken into a shopand with the drawing as a guide the piece could be produced. In these drawings care should be exercised to produce awell-balanced sheet, to place the views so…
