the otherend of the cylinder. The steam then enters at the port p^and, in the same manner,pushes the piston back.The piston in turn pushesthe dead steam which isin the other end of thecylinder out through theport^, which in the mean-time has been opened by theconnecting-rod r; and fromthe… … §§281-283] HEAT AND WORK 167 enlarged, so that the process may be more easily followed ;74 shows the steam just beginning to force the pistonback; and 75 shows the piston travelling in -the oppositedirection just as the steam from the steam-chest andboiler is shut off from the cylinder. 282.…
