Fig. 39.—Compoundblock pulley. 82 PHYSICS the advantage is greater the longer d is, with respect to s—■that is, the smaller the angle of the plane — a. i d ws = pa, or w = — p. sAs a increases from 0° to 90°, we can easily see that thepressure, p, must be increased, as the plane gets steeper, … F;g. 40.—Inclined plane. and will finally equal the weight, w, when the plane is ver-tical. Then w — p. In Fig. 41 the weight is represented by a straight line,c g (which, as we have seen, must always be vertical andmust start from the center of gravity, c). This is the only
