Set for Siding Fig. 37 Set for Main Line … to\\Ti. One form of safety switch and frog — the MacPherson— is sho^^^l in Figs. 37 and 38. Its operation will be clear fromthe figures. Double Turnouts. — The track arrangement for a double turn-out with a stub switchshown in Figs. 39 and 40,is called a three-throwswitch, and for such aswitch…
