explainedin Constructive Carpen-try. The long side of theframing square is known asthe * blade, and the shortside as the ^ tongue. 32. The bevel (Fig. 33)may be set for use in mark-ing and testing any angle,,,in the same manner thatthe try-square is used uponrectangular work. Thesketch shows the… … Fig. 33. — Bevel and Steel Square.The bevel is set at an angle of 45°. TOOLS 63 is for the purpose of niak-or working side or edge.
