Engelman's autocraft; being an instructive study of the automobile; its care and management; how to drive; locating troubles and repairing them; with chapters exploiting some of the latest devices used in automobile construction (1914)
Engelman, Roy Albert, b. 1889 · Cincinnati, O., The American chauffeur publishing co. · leaf 168
ng the two spokes in a perpen-dicular line—one above and one below the hub—you begin to feel a very slight shake in the wheel.If this is more than barely perceptible, it is toomuch, and the adjusting nut should be a littletighter. When you have it just right, lock it, and thebearings will give the… … (All Dimensions in Inches.) D = Distance between centers./i:=Distance between limits of contact.i?^Pitch radius of large sprocket. r=:Pitch radius of small sprocket.A^=Number of teeth on large sprocket. n:=Number of teeth on small sprocket.PrzPitch of chain and sprockets.180° + 2a:=Angle of…
Automobiles
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
