dfrom revolving, the pinions will rotate on the weband thus allow the gear G to revolve, carryingwith it axle A and wheel W. If gear G revolves slowly, gear G can revolverapidly, or vice versa, because the difference intheir motion is compensated for by the rotationsof pinions P—P. It will also be… … Figure 2. tvveen the centers of the pinions and the teeth ofboth gears are ahvays equal. In the simplest language possible, when gear Gremains stationary, gear G and the pinions rollaround, as it were, on gear G, the teeth of thepinions pressing forward on the teeth of gears Gand G with equal…
